ACTION AND ADRENALINE
Invader Raft M
ACTION AND ADRENALINE
Highest air pressure, highest stability
The INVADER carries over every whitewater! The bow and stern are not fragmented, but bent harmoniously round. The raft behaves noticeably more agile, is more comfortable controllable and glides better over waves. Extremely robust for years in use, also suitable as a lifeboat, for water sports centers and clubs or competition organizers. The maximum security for passengers and guides – and the best choice for your rafting company!
The boat
Robust and safe
Double & replaceable boat-skin: A second boat-skin, which reinforces the raft at the external side tubes and along the bottom, allows it to withstand impacts against rocks or ground contact under heavy loads. The double boat-skin can be replaced if worn.
Absolutely safe and extremely durable!
All-round safety
An ingenious difference that is included as standard: the continuous safety-bulkheads. In the event of damage, the boat retains air along its entire length and does not sink neither to the front nor to the rear. You can continue your journey safely.
Stabilising rolls
Two inflatable rolls add incredible stiffness to the raft.
Safe seats.
The anti-slip seat-covering on the side tubes increases passenger safety.
Quick bailing-holes.
For optimum drain: The bailing-holes along the bottom sides of the boat ensure that splashed water is drained off quickly.
Strong throughout
The thick circumferential line, which is used to hold and carry the raft, is attached to sturdy triangular brackets.
The large bow and stern handles are used to carry and tie the raft.
More safety
The basic equipment of the boat includes everything you need for rafting. Additional, individual safety equipment is optionally available.
- Narrow conical foot-caps provide good grip for your feet. Their special shape prevents your feet from getting stuck by mistake or slipping through.
- The boarding handles on the right and left ends of the seatrolls make it easy to pull yourself up from the water into the boat.
- Entry arrow markings help you find the boarding handles.
INVADER - Available in 3 sizes
| S | 390 cm | for 6 passengers + 1 guide = 7 persons |
| M | 440 cm | for 8 passengers + 1 guide = 9 persons |
| L | 490 cm | for 10 passengers + 1 guide = 11 persons |
Pictures & Videos
Technical data
| Overall Length x Width | 440 x 212 cm | 14' 5" x 6' 11" |
| Inside Length x Width | 360 x 100 cm | 11' 9" x 39" |
| Hose diameter | 56 cm | 22" |
| Weight | 60 kg | 132 lbs |
| Pack size L x W x H | 120 x 55 x 35 cm | 47" x 22" x 14" |
| Persons max. | 9 | 9 |
| Payload | 1830 kg | 4034 lbs |
| Air Chambers | 7 | 7 |
| Assembly Time | 25 min | 25 min |
| Operating Pressure | 0.3 bar | 4.3 psi |
| Material | 1100 dtex EPDM-Kautschuk | 1100 dtex EPDM-Kautschuk |
| White water category | 6 | 6 |
| ISO Standard | ISO EN 6185 cat. I | ISO EN 6185 cat. I |
| Design Category | C | C |
| Colour | red-black | red-black |
| Still Waters |
|
|
| Rivers |
|
|
| White water |
|
|
| Capsize stability |
|
|
| Get in the water |
|
|
Standard equipment
- 7 safety valves
- 3 pressure relief valves
- 2 seat rolls
- 4 seat roll fittings
- 10 stainlesss steel triangles
- safety- and carrying line
- 2 carrying handles
- 1 specification label
- 1 repair kit
- 1 valve key
- 1 air-valve adapter bayonet
- 1 owners manual with declaration of confirmity
